5
0
-5
-10
-15
-20
-25
-30
-35
-40
-45
-1 0 1
10 10 10
Figure 8. Jitter Attenuation Characteristics of PLL with
8 to 96 kHz Fs Filter Components-ILRCK
Fsi Range (kHz)
8 to 96
32 to 96
14
Digital Bode plot
2 3 4
10 10 10
Frequency (Hz)
RFILT (k Ω ) CFILT ( µ F)
0.909
5.1

Table 2. PLL External Components using ILRCK

5
0
-5
-10
-15
-20
-25
-30
-35
-40
-45
5 -1 0
10 10 10
Figure 9. Jitter Attenuation Characteristics of PLL with
32 to 96 kHz Fs Filter Components-ILRCK
CRIP (nF)
2.2 33
150 3.9
Digital Bode plot
1 2 3
10 10 10
Frequency (Hz)
PLL Lock Time (ms)
56
15
CS8427
4 5
10 10
DS477PP1
