2. Wi-Fi Connection: "MSP Not Found" (cont.)
NOTE: DO NOT hold down the reset button (back of the HLWLAN) for more than
10 seconds.
Verify HLWLAN connections On HLWLAN, inspect LEDs
Step 2C
Step 2D
Verify the cable from the MSP is plugged into the LAN On the back of the HLWLAN, verify both the Power LED
port on the injector. Then verify the cable plugged into & at least one of the LAN LEDs is ON or Flashing. This
the HLWLAN's LAN (POE) port plugs into the injectors will indicate whether or not power has been supplied
POE port. Finally, verify the injectors power cable is to the HLWLAN and if communication has been
plugged firmly into the OmniLogic MPP. IF correct, go established with the local area network. IF LEDs are not
to step 2D. IF incorrect, fix & repeat steps on pg. 15-18). ON, go to 2E. IF correct, jump to step 2H.
