OmniLogic: Main System Processor (MSP)
A2
B2
7
HLX-LOC-DSP
A2
Ethernet Port (used for both Wired & Wi-Fi network operation)
B2
USB Port (uploading firmware & backing up/loading configuration)
C2
MSP Connection (Input/Output)
D2
MSP Ribbon Cable
E2
MPP Connection (Input/Output)
C2
D2
E2
A2
B2
