OmniLogic® Wireless Remote
How To Guide
HTG-HLWL220a
Copyright 2017 Hayward Industries Inc.

Advertisement

loading
Need help?

Need help?

Do you have a question about the OmniLogic and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hayward OmniLogic

Summary of Contents for Hayward OmniLogic

  • Page 1 OmniLogic® Wireless Remote How To Guide HTG-HLWL220a Copyright 2017 Hayward Industries Inc.
  • Page 2 Remote: Product Overview • The OmniLogic HLWIRELESS Wireless Terminal is a rechargeable touchscreen remote control for Hayward OmniLogic. • The terminal is wireless and portable. Its unique watertight housing and floating design allows it to be used outdoors, even while inside the pool or spa*.
  • Page 3 Remote: Requirements & Tech Specs The following outlines the technical requirements and specifications related to the Wireless Remote and subsequent hardware. Min. Firmware Rev. Equipment *2.0.0* Wired Wall Mount (WDT) 2.0.0 Main System Processor (MSP) 1.0.5 Main Panel Processor (MPP) Specifications 6.34, 3.5, 4.0 (“) Product Dimensions (L,W,H includes base) 2lbs...
  • Page 4 Remote: How Communication Works The Hayward Wireless Waterproof Remote communicates to the home network router, through the 2.4 Ghz Wi-Fi. It DOES NOT connect directly to the OmniLogic or HLWLAN. Important: The remote MUST be connected to the same network as the OmniLogic;...
  • Page 5 How To: Sync Remote with Network Use the steps provided to synchronize the HLWIRELESS with the home network. Step 1 Step 2 Upon boot-up the Hayward Logo will appear. Once the “Welcome” screen appears, tap “OK”. Step 3 Step 4 Select the network name from the list.
  • Page 6 Config>Network. If it still seen on the MSP. fails reset the Wireless Remote (next section). NOTE: IF the OmniLogic is connected to Wi-Fi, make sure the HLWIRELESS is connected to the same network and not one with a different SSID or network name.
  • Page 7 How To: Reset the Remote Use the steps provided to reset the HLWIRELESS remote. Step 1 Step 2 Take the remote out of its cradle. Flip the charging cradle upside-down, revealing the bottom. Step 3 Step 4 Locate the label on the bottom of the base and Holding the remote face up, hover the remote the small “R”...
  • Page 8 How To: Reset the Remote Use the steps provided to reset the HLWIRELESS remote. Step 5 Step 6 When the screen goes completely blank, tap on Place the remote back in the charging cradle, at the screen to verify it is rebooting. this point the remote should reboot.
  • Page 9 How To: Download Firmware To download the latest firmware to a USB drive go to www.hayward.com Support Center> Automation > OmniLogic > Firmware Updates Step 1: Right click on the link of the Step 1-3 file you wish to download.

  • Page 10: How To: Upgrade Firmware

    How To: Upgrade Firmware Insert the USB drive into the side of the MSP and follow the steps provided below: Step 1 Step 2 Press the power button. Select “service mode”. Step 3 Step 4 Tap the “Upgrade” icon. Tap the device to upgrade then check mark.
  • Page 11 How To: Upgrade Firmware (cont.) NOTE: Make sure all devices are up to the latest firmware revision. Step 5 Step 6 Select storage method (USB). Select latest file (downloaded from web). Step 7 Step 8 Press check mark to start the upgrade process Press check mark when complete (100%), (DO NOT power off while in process).
  • Page 12 How To: Interpret Wi-Fi Status The Wi-Fi indicator located in the top right of the remote, reveals the relationship between the wireless remote, the OmniLogic, and the network router. Normal Connection: the Wireless Terminal is connected to the OmniLogic MSP, this is normal operation.
