How To: Connect Directly Via Ethernet
Use these steps to directly connect the MSP to a home router.
Step 1
Step 2
OmniLogic Enclosure
Before installing the OmniLogic, it is advisable
If crimping cable, follow above diagram for
to run Ethernet to the installation site*.
CAT6 (right), verify wires match.
Step 3
Step 4
Test the Ethernet wire using a LAN tester to
Connect Ethernet cable to the router/modem.
confirm cable integrity and wiring. LAN testers
Make sure the cable IS NOT plugged in to a PoE
are critical to qualifying data cabling.
or WAN port.
