To Clean The Rollers; Figure 2-4 Tape Drive - Sun Microsystems Enterprise Tape Library 7/3500 Field Service Manual

Tape Drive
FIGURE 2-4

To Clean the Rollers

See .
FIGURE 2-5
1. Lightly dampen a cloth (supplied in PM kit) with isopropyl alcohol.
2. Remove all dust and debris from the:
Two rollers on the y-axis assembly
Four rollers on the x-axis assembly
3. Remove dust and debris from the running surfaces of the:
X-axis guide (part of the library frame)
Tape drive
Tape drive receiver
Chapter 2 Preventive Maintenance
Front door
TJ00071a
31
