Figure A-2 Menu Structure - Sun Microsystems Enterprise Tape Library 7/3500 Field Service Manual

The control panel's main display area consists of the following screens:
Overview
Tapes
Operator
Service
FIGURE A-2
Overview
Tape Drive Status
CHM Activity
Load Port
FIGURE A-2
164 Sun Enterprise Tape Library 7/3500 Field Service Manual • July 1997
lists the structure of the control panel main display area.
MAIN DISPLAY AREA
Tapes
Tape Drives
Storage
Load Pack
Transport
Menu Structure
Operator
Configure Library
Configure Options
Move Cartridges
Inventory Dataset
Calibrate Library
Exercise Library
Unload Drives
Unload Imp/Exp
Service
Statistics
Actuator
Sys Test Results
Sys Test Library
Operate Axes
Initialize Nonvol Stats
Initialize Nonvol Config
Change Password
