Figure 1-8 X-Carriage Assembly - Sun Microsystems Enterprise Tape Library 7/3500 Field Service Manual

Hide thumbs
Table of Contents

Advertisement

X-axis motor
assembly
X-axis sensor
rail
X-carriage
assembly
FIGURE 1-8
16
Sun Enterprise Tape Library 7/3500 Field Service Manual • July 1997
X-Carriage Assembly
X-axis confirmation
sensor
Y-axis motor pulley
TJ00067A
