Reassembling the Library

Replacing the Cosmetic Panels

Use the procedures below along with
page 95 to replace the cosmetic panels.

To Replace the Front Panel

Caution – You must replace the front panel before replacing the top, left or right
panels.
1. Position the front panel at the front of the library.
2. Reconnect control panel ribbon connector A3_J1.
3. From the front of the library, pick up the front panel and replace it on the library
frame (from bottom to top).
4. Reconnect the remaining miscellaneous sensors cable assembly connectors.
a. Plug SW1 blade lug black wire onto the bottom (common) spade of SW1.
b. Plug SW1 blade lug white wire onto the top (N.C.) spade of SW1.
c. Plug SW2 blade lug black wire onto the bottom (common) spade of SW2.
d. Plug SW2 blade lug white wire onto the top (N.C.) spade of SW2.
e. Reconnect the front door interlock switch in-line connector SW2_J1.
f. Reconnect the load port solenoid in-line connector SOL_J1.
5. Reinstall the mounting screws.
6. From the right side of the library, reinstall the EMI cover.

To Replace the Left Panel

1. Rest the top lip of the left panel on the top of the library frame.
2. Push the panel towards the front of the library and insert the frame buckles into
the retention tabs.
on page 92 and
FIGURE 4-1
Chapter 4 FRU Removal and Replacement
on
FIGURE 4-2
159
