Figure 1-2 Library Numbering Conventions-100 Cartridge Model, Left-Side View - Sun Microsystems Enterprise Tape Library 7/3500 Field Service Manual

Fixed storage array
(FSA) bins
FIGURE 1-2
4 Sun Enterprise Tape Library 7/3500 Field Service Manual • July 1997
Bin 0 Bin 24 Bin 48
Bin 1 Bin 25 Bin 49
Bin 2 Bin 26 Bin 50
Bin 3 Bin 27 Bin 51
Bin 4 Bin 28 Bin 52
Bin 5 Bin 29 Bin 53
Bin 6 Bin 30 Bin 54
Bin 7 Bin 31 Bin 55
Bin 8 Bin 32 Bin 56
Bin 9 Bin 33 Bin 57
Bin 10 Bin 34 Bin 58
Bin 11 Bin 35 Bin 59
Bin 12 Bin 36 Bin 60
Bin 13 Bin 37 Bin 61
Bin 14 Bin 38 Bin 62
Bin 15 Bin 39 Bin 63
Bin 16 Bin 40 Bin 64
Bin 17 Bin 41 Bin 65
Bin 18 Bin 42 Bin 66
Bin 19 Bin 43 Bin 67
Bin 20 Bin 44 Bin 68
Bin 21 Bin 45 Bin 69
Bin 22 Bin 46 Bin 70
Bin 23 Bin 47 Bin 71
Library Numbering Conventions—100 Cartridge Model, Left-Side View
Bin 72
Bin 0
Bin 73
Bin 1
Bin 74
Bin 2
Bin 75
Bin 3
Bin 76
Bin 77
Bin 78
Bin 79
Drive 0
Bin 80
Bin 81
Bin 82
Drive 1
Bin 83
Bin 84
Bin 85
Drive 2
Bin 86
Bin 87
Drive 3
Bin 88
Bin 89
Drive 4
Bin 90
Bin 91
Bin 92
Drive 5
Bin 93
Bin 94
Drive 6
Bin 95
Load port
bins
Tape
drives
TJ00001A
