Mechanical Inspection Entry MAP

1. Inspect drive belts
2. Check for movement
3. Check cartridges
Inspect and manually move the
x-axis belt (see
page 40).
Belt and motor appear OK?
Inspect and manually move the
y-axis belt (see
page 37).
Belt and motor appear OK?
Inspect and manually move the
extension axis belt (see
on page 40).
FIGURE 2-11
Belt and motor appear OK?
Verify that the cartridges are
fully seated in the storage array.
See "Fault Isolation Entry
MAP" on page 48.
50 Sun Enterprise Tape Library 7/3500 Field Service Manual • July 1997
on
FIGURE 2-11 No
Yes
on
FIGURE 2-9
No
Yes
No
Yes
No
Yes
1.Tighten or adjust as required
(see page 37).
2. Replace if required (see
page 116).
1. Tighten or adjust as required (see
page 35).
2. Replace if required (see page 118).
1. Tighten or adjust as required (see
page 41).
2. Replace if required (see "X-Axis
Drive Belt" on page 116).
Seat cartridges.
