To Remove the Right Panel

Caution – You must remove the top panel before removing the right panel.
1. Remove power from the library.
Caution – DO NOT disconnect the power cord from facility power or the library.
The power cord is the only means of grounding the chassis and helping to prevent
electrostatic discharge (ESD) damage.
2. At the rear of the library, remove the screws that secure the right panel to the rear
of the library frame (
3. Open the drive bay door and remove the remaining screws securing the panel.
4. Pull the panel away from the frame.
5. Set aside the panel.

To Remove the Front Panel

Caution – Employ all appropriate measures to protect the library from ESD
damage.
1. Remove power from the library.
Caution – DO NOT disconnect the power cord from facility power or the library.
The power cord is the only means of grounding the chassis and helping to prevent
electrostatic discharge (ESD) damage.
2. Remove the top, right, and left cosmetic panels.
3. From the right side of the library, remove the screws that mount the EMI cover to
the library frame (
FIGURE 4-2
4. Pull away the EMI cover.
5. From the front top of the library, remove the screws that secure the upper
mounting lip of the front panel to the library frame.
6. From the lower front inside of the library, remove the screws that hold the lower
mounting lip of the front panel to the library frame.
7. Disconnect load port solenoid in-line connector SOL_J1.
).
FIGURE 4-1
).
Chapter 4 FRU Removal and Replacement 93
