Connectors - AXIOMTEK SHB150R Series User Manual

2.4

Connectors

Signals go to other parts of the system through connectors. Loose or improper connection
might cause problems. Make sure all connectors are properly and firmly connected. Here is a
summary table showing all connectors on the hardware.
1 ATX Power Connector (ATX1)
2 DDR4 Socket (DIMM1.DIMM2)
3 Internal USB 3.1 Gen1 Connector (CN3)
4 TPM Pin Header (CN2)
5 FAN Connectors (FAN1)
6 FAN Connectors (FAN2)
7 Parallel Port Connector (PRINT1)
8 SATA 3.0 Connectors (SATA1~SATA6)
9 COM Connectors (COM1)
10 COM Connectors (COM2)
11 COM Connectors (COM3)
12 COM Connectors (COM4)
®
13 Intel HD Audio Digital Header (HDA1)
14 Restore BIOS Optimal Defaults (JP2)
15 Auto Power On (JP3)
16 M.2 2280 Key M NVMe SSD (CN4)
32 Ethernet Ports (CN5)
32 Ethernet Ports (CN5)
Board and Pin Assignments
Jumpers/Headers/Connectors
Rear I/O Jumpers/Headers/Connectors
SHB150R LGA1151 Full-size CPU Card
17 Front Panel Connector (CN8)
18 Buzzer (BZ1)
19 Internal USB2.0 Headers (CN10)
20 RTC Battery Socket (BAT1)
21 FAN Connectors (FAN3)
22 9th/8th Intel® Coffee Lake LGA 1151 socket
23 PICMG_1.3 Gold Finger
24 PICMG_1.3 Gold Finger
25 PICMG_1.3 Gold Finger
26 PICMG_1.3 Gold Finger
27 Internal PS/2 Mouse Connectors (CN13)
28 Internal PS/2 Keyboard Connectors (CN14)
29 Temperature Sensor Connector (CN1)
30 Internal USB 3.1 Gen2 Connector (CN7)
31 Display Port 1.4 Connector (CN11)
34 DVI-I Connector (CN9)
Rear I/O l USB 3.1 Gen1 Connectors (CN12
35
and CN15)
