AXIOMTEK SHB150R Series User Manual page 83

x8 PCIe Connector B
No. Side B
1 +5Vaux
2 GND
3 a_PETp8
4 a_PETn8
5 GND
6 GND
7 a_PETp9
8 a_PETn9
9 GND
10 GND
11 N.C
12 GND
13 a_PETp10
14 a_PETn10
15 GND
16 GND
17 a_PETp11
18 a_PETn11
19 GND
20 GND
21 a_PETp12
22 a_PETn12
23 GND
24 GND
25 a_PETp13
26 a_PETn13
27 GND
28 GND
®
PICMG v1.3 Interface Definition
Side A No.
+5Vaux 1
N.C 2
GND 3
GND 4
a_PERp8 5
a_PERn8 6
GND 7
GND 8
a_PERp9 9
a_PERn9 10
GND 11
Mechanical Key
N.C 12
GND 13
GND 14
a_PERp10 15
a_PERn10 16
GND 17
GND 18
a_PERp11 19
a_PERn11 20
GND 21
GND 22
a_PERp12 23
a_PERn12 24
GND 25
GND 26
a_PERp13 27
a_PERn13 28
SHB150R LGA1151 Full-size CPU Card
x8 PCIe Connector D
Side B
INTB#
INTD#
GND
REQ3#
REQ2#
PCI_RST#
REQ1#
REQ0#
N.C
GND
N.C
CLKC
GND
CLKA
+3.3V
AD31
AD29
N.C
AD27
AD25
GND
C/BE3#
AD23
GND
AD21
AD19
+5V
AD17
Side A
INTA#
INTC#
N.C
GNT3#
GNT2#
GNT1#
GNT0#
SERR#
+3.3V
N.C
GND
CLKD
+3.3V
CLKB
GND
GND
+3.3V
AD30
AD28
GND
AD26
AD24
+3.3V
AD22
AD20
N.C
AD18
AD16
