2.5

Connectors

Signals go to other parts of the system through connectors. Loose or improper connection
might cause problems, please make sure all connectors are properly and firmly connected.
Here is a summary table which shows all connectors on the hardware.
Connector
CN2
CN3
CN4
CN5
CN6
CN7
CN8
CN9
CN10
CN11
CN12 (Optional)
CN13
CN14
CN15
CN16
CN17
SCN1
SCN2
Board and Pin Assignments
Description
Board to Board Connector 1 (Low Speed)
Board to Board Connector 2 (High Speed)
SATA Connector
CMOS Battery Connector
Fan Power Connector
Digital I/O Connector
SATA Power Connector
Front Panel Connector
USB 2.0 Wafer Connector
Inverter Connector
Power Wafer Connector
Ethernet Port
DC Jack Power Connector w/ Screw
HDMI Connector
LVDS Connector
I2C Connector
Full-size PCI-Express Mini Card and mSATA Connector
DDR4 SO-DIMM Connector
PICO512 Pico-ITX Board
13
