2.4

Connectors

Signals go to other parts of the system through connectors. Loose or improper connection
might cause problems, please make sure all connectors are properly and firmly connected.
Here is a summary table of connectors on the hardware.
Connector
CN1
CN2
CN3
CN4
CN5
CN6
CN7
CN11
CN12
CN13
CN14
CN15
CN16
CN17 (Optional)
CN18
CN19
CN20
CN21
CN22
CN23 (Optional)
ATX1
LAN1~LAN2
SCN1
SCN2
SCN3
SCN4 (Optional)
SDIMM1
Board and Pin Assignments
Description
SMBus Connector
Front Panel Connector
COM4 Wafer Connector
COM3 Wafer Connector
Audio Connector
Digital I/O Connector
USB 2.0 Wafer Port 4 and 5
I2C Connector
SATA Power Connector
Fan Connector
Inverter Connector
SATA Connector
LVDS Connector
COM1 Wafer Connector
COM2 Wafer Connector
HDMI Connector
USB 3.0 Port 0 and 1
USB 3.0 Port 2 and 3
COM1 D-Sub Connector
VGA Connector
ATX Power Connector
Ethernet Port 1 and 2
Full-size PCI-Express Mini Card Connector
SIM Card Socket
Full-size PCI-Express Mini Card or mSATA Connector
eDP Connector
DDR3L SO-DIMM Connector
CAPA312 3.5" Board
11
