2.5

Connectors

Signals go to other parts of the system through connectors. Loose or improper connection
might cause problems, please make sure all connectors are properly and firmly connected.
Here is a summary table of connectors on the hardware.
Connector
CN1
CN2
CN4
CN5
CN7
CN8
CN9, CN11
CN10
CN12
CN13
CN14, CN16
CN15
CN17
CN18
CN19
CN20, CN21
CN22, CN23
ATX1
SCN1
SCN2
DIMM1
12
Description
LVDS Connector
Front Panel Connector
Inverter Connector
USB 2.0 Wafer Connector
SIM Card Wafer Connector
Digital I/O Connector
COM1 and COM2 Wafer Connectors
M.2 2242/3042 Key B Connector
SATA Connector
M.2 2230 Key E Connector
Ethernet Port 4 and Port 3 Wafer Connectors
SATA Power Connector
Audio Wafer Connector
USB 3.1 Port 1 and 2
DisplayPort Connector
HDMI Connectors
Ethernet Port 1 and 2
ATX Power Connector
Fan Connector
DC +5V/15W Power Output Connector
DDR4 SO-DIMM Connector
Board and Pin Assignments
