Appendix E Picmg V1.3 Interface Definition - AXIOMTEK SHB150R Series User Manual

SHB150R LGA1151 Full-size CPU Card
PICMG
x16 PCIe Connector A
No. Side B
1 N.C
2 GND
3 N.C
4 N.C
5 N.C
6 PWRBT#
7 PWRGD
8 SHB_RST#
9 CFG0
10 CFG2
11 RSVD
12 GND
13 b_PETp0
14 b_PETn0
15 GND
16 GND
17 b_PETp1
18 b_PETn1
19 GND
20 GND
21 b_PETp2
22 b_PETn2
23 GND
24 GND
25 b_PETp3
26 b_PETn3
74
®
v1.3 Interface Definition
Side A No.
N.C 1
GND 2
N.C 3
N.C 4
WAKE# 5
PME# 6
PSON# 7
PERST# 8
CFG1 9
CFG3 10
GND 11
Mechanical Key
N.C 12
GND 13
GND 14
b_PERp0 15
b_PERn0 16
GND 17
GND 18
b_PERp1 19
b_PERn1 20
GND 21
GND 22
b_PERp2 23
b_PERn2 24
GND 25
GND 26
Appendix E
x16 PCIe Connector C
Side B Side A
USB0P GND
USB0N GND
GND USB1P
GND USB1N
USB2P GND
USB2N GND
GND USB3P
GND USB3N
USBOC0# GND
GND USBOC1#
USBOC2# GND
GND USBOC3#
N.C GND
N.C GND
GND N.C
GND N.C
N.C GND
N.C GND
GND N.C
GND N.C
N.C GND
N.C GND
GND N.C
GND N.C
N.C GND
N.C GND
®
PICMG v1.3 Interface Definition
