Packing List - AXIOMTEK SHB150R Series User Manual

 Ethernet
 LAN1/LAN2: Intel
 Support 1000/100/10Mbps Gigabit/Fast Ethernet

Storage
 Serial ATA:
Six SATA 3.0 ports (6Gbps performance) with SATA RAID 0/1/5/10 (Q370/C246)
Four SATA 3.0 ports (6Gbps performance) (H310)
 One M.2 2280 Key M (Only for Q370, C246 version)
 Audio
 Supports HD audio interface as a 2x8 pin header
 Supports audio kit AX93242 with MIC-in/Line-in/speaker-out (option kit)
 Watchdog Timer
 1~255 seconds or minutes; up to 255 levels
 Hardware Monitoring
 Monitoring temperatures, voltages and cooling fan status
 Dimensions
 338mm x 126mm
 Expansion Interface
 One PCI-Express x16 (Gen.3)
 One PCI-Express x4 (or four PCI-Express x1) (Gen.3)
 Four PCI
All specifications and images are subject to change without notice.
Note
1.3

Packing list

 1 x slot CPU card
 1 x Driver DVD

1 x SATA cable

1 x COM cable
Introduction
®
i219LM with iAMT / Intel
SHB150R LGA1151 Full-size CPU Card
®
i211AT Ethernet controller
3
