Management Support

¥ MIB II, 802.1d, 802.3, and Cabletron Enterprise MIB
¥ Cabletron Systems Local Console Manager (LCM)
¥ Any SNMP-based network management system

Regulatory Compliance

Safety
Electromagnetic Compatibility
A.2 SERIAL CABLE PIN ASSIGNMENTS
For a PC running a Windows terminal connected to the RS232C Network
Management Port on the front panel of the SmartSTACK Ethernet
ELS10-27, the following serial cable pin assignments (tables A-1 and A-2)
are required to manage the SmartSTACK Ethernet ELS10-27 using the
Local Console Manager (LCM).
SmartSTACK Ethernet ELS10-27
RJ45 (female)
Pin 1 (Tx)
Pin 4 (Rx)
Pin 5 (GND)
This equipment meets the safety
requirements of UL 1950, CSA C22.2
No. 950, EN 60950, IEC 950, and
73/23/EEC
This equipment meets the
requirements of FCC Part 15,
EN 55022, EN 50082-1, 89/336/EEC
CSA C108.8, VCCI V-3, AS/NZS 3548
Table A-1. DB25 Pin Assignments

Serial Cable Pin Assignments

DB25-pin (female)
Pin 3
Pin 2
Pin 7
A-3
