  • Page 1 SmartSTACK ELS100-S24TX2M FAST ETHERNET SWITCH USER GUIDE 9033260-01...
  • Page 3 NOTICE Cabletron Systems reserves the right to make changes in specifications and other information contained in this document without prior notice. The reader should in all cases consult Cabletron Systems to determine whether any such changes have been made.

  • Page 4: Fcc Notice

    Notice FCC NOTICE This device complies with Part 15 of the FCC rules . Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC rules.
  • Page 5 Notice CABLETRON SYSTEMS, INC. PROGRAM LICENSE AGREEMENT IMPORTANT: THIS LICENSE APPLIES FOR USE OF PRODUCT IN THE FOLLOWING GEOGRAPHICAL REGIONS: CANADA MEXICO CENTRAL AMERICA SOUTH AMERICA BEFORE OPENING OR UTI LIZING THE ENCLOSED PRODUCT, CAREFULLY READ THIS LICENSE AGREEMENT. This document is an agreement (“Agreement”) between You, the end user, and Cabletron Systems, Inc.
  • Page 6 Notice If the Program is exported from the United States purs uant to the License Exception TSR under the U.S. Export Administration Regulations, in addition to the restriction on transfer set forth in Sections 1 or 2 of this Agreement, You agree not to (i) reexport or release the Program, the source code for the Program or technology to a national of a country in Country Groups D:1 or E:2 (Albania, Armenia, Azerbaijan, Belarus, Bulgaria, Cambodia, Cuba, Estonia, Georgia, Iraq, Kazakhstan, Kyrgyzstan, Laos, Latvia, Libya, Lithuania, Moldova, North Korea, the People’s Republic of China,...
  • Page 7 BEFORE OPENING OR UTI LIZING THE ENCLOSED PRODUCT, CAREFULLY READ THIS LICENSE AGREEMENT. This document is an agreement (“Agreement”) between You, the end user, and Cabletron Systems Sales and Service, Inc. (“Cabletron”) that sets forth your rights and obligations with respect to the Cabletron software program (“Program”) in the package.
  • Page 8 Notice If the Program is exported from the United States pursuant to the License Exception TSR under the U.S. Export Administration Regulations, in addition to the restriction on transfer set forth in Sections 1 or 2 of this Agreement, You agree not to (i) reexport or release the Program, the source code for the Program or technology to a national of a country in Country Groups D:1 or E:2 (Albania, Armenia, Azerbaijan, Belarus, Bulgaria, Cambodia, Cuba, Estonia, Georgia, Iraq, Kazakhstan, Kyrgyzstan, Laos, Latvia, Libya, Lithuania, Moldova, North Korea, the People’s Republic of China,...
  • Page 9 Notice CABLETRON SYSTEMS LIMITED PROGRAM LICENSE AGREEMENT IMPORTANT: THIS LICENSE APPLIES FOR THE USE OF THE PRODUCT IN THE FOLLOWING GEOGRAPHI CAL REGIONS: EUROPE MIDDLE EAST AFRICA ASIA AUSTRALIA PACIFIC RIM BEFORE OPENING OR UTI LIZING THE ENCLOSED PRODUCT, CAREFULLY READ THIS LICENSE AGREEMENT.
  • Page 10 Notice If the Program is exported from the United States pursuant to the License Exception TSR under the U.S. Export Administration Regulations, in addition to the restriction on transfer set forth in Sections 1 or 2 of this Agreement, You agree not to (i) reexport or release the Program, the source code for the Program or technology to a national of a country in Country Groups D:1 or E:2 (Albania, Armenia, Azerbaijan, Belarus, Bulgaria, Cambodia, Cuba, Estonia, Georgia, Iraq, Kazakhstan, Kyrgyzstan, Laos, Latvia, Libya, Lithuania, Moldova, North Korea, the People’s Republic of China,...

  • Page 11: Declaration Of Conformity

    Notice DECLARATION OF CONFORMITY Ap plication of Co uncil Directive(s): 89/336/EEC 73/23/EEC Manu factu rer’s Name: Cabletron Sy stems, I nc. M anufacturer’s Ad dres s: 35 I ndustrial Wa y PO Bo x 500 5 Roches ter, NH 03 867 Europ ean Representative Name: Mr.

  • Page 13: Table Of Contents

    TABLE OF CONTENTS PREFACE ........... . . XIII Purpose .
  • Page 14 APPENDIX B. FLOW CONTROL ........35 APPENDIX C. ACRONYMS & ABBREVIATIONS ..... . 37 INDEX xii T able of Contents ELS100-S24TX2M...

  • Page 15: Preface

    PREFACE Purpose This guide provides information about the features and applications of the Cabletron Systems SmartSTACK ELS100-S24TX2M stackable switch system. Audience This guide is intended for Ethernet Local Area Network (LAN) administrators and Management Information Systems (MIS) personnel with the following background: •...

  • Page 16: Other Conventions

    Appendix C. Acronyms and Abbreviations: Provides definitions for a list of common acronyms and abbreviations used within the installation guide and the networking industry. xiv Preface ELS100-S24TX2M...

  • Page 17: Product Overview

    Application Example Description This installation guide describes Cabletron Systems’ SmartSTACK ELS100-S24TX2M Fast Ethernet switch. The switch provides 24 10Base-T/100Base-TX ports, plus two slots for optional slide-in 100Base-FX, 1000Base-SX or 1000Base-LX modules. One of these slots can also be used for an optional Stacking Module that allows you to attach up to four switches to a 4 Gbps high-speed backplane.

  • Page 18: Features

    Microsoft’s Internet Explorer. In addition, the console port allows out-of- band management using a PC, terminal, or modem connection. The ELS100-S24TX2M switch is desktop or rack-mountable. LEDs on the front panel provide information about the operating status of the switch.
  • Page 19 • Switch Architecture: - 3 controllers with 8 10/100 ports - IEEE 802.3u auto-negotiation of half/full-duplex operation on all RJ-45 ports - Up to 4 switch units can be stacked together, supporting up to 100 connections - 128 KB packet buffering for 10/100 ports, 2 MB packet buffering for 1000 ports - Store-and-forward switching - 8K address forwarding table...

  • Page 20: Front Panel

    Front Panel Figure 1-1 shows the front panel of the Cabletron Systems SmartSTACK ELS100-S24TX2M. Table 1-1 defines the ELS100-S24TX2M front panel components. Figure 1-1. ELS100-S24TX2M Front Panel Table 1-1. Front Panel Components Name Function Power LED Lights steady green to indicate power is supplied to the switch.

  • Page 21: Optional Modules

    Optional Modules Figure 1-2 shows the optional modules available for the Cabletron Systems SmartSTACK ELS100-S24TX2M. Table 1-2 defines the optional module components. Figure 1-2. Optional Modules Table 1-2. Optional Module Components Module Components 100Base-FX (MMF) Ports: Two multi-mode fiber ports using SC connectors for uplink.

  • Page 22: Rear Panel

    Console port: Male DB-9 connector configured as a null modem connection for serial out-of-band management using the console menus. Rear Panel Figure 1-3 shows the ELS100-S24TX2M rear panel and Table 1-3 defines the rear panel components. Figure 1-3. ELS100-S24TX2M Rear Panel Table 1-3. Rear Panel Components...

  • Page 23: Feature Summaries

    To minimize the possibility of dropping frames on congested ports, the ELS100-S24TX2M switch provides 128 KB of frame buffering per port. This buffer space is used to queue packets for transmission on congested networks. This is an additional advantage over cut-through switching technology, which drops packets immediately when experiencing collisions.

  • Page 24: Software Download

    These values are retained when the switch experiences power interruptions or is powered down for normal maintenance. Configuration and Management Interfaces The ELS100-S24TX2M switch, or attached stack, can be managed using any of the following methods: • Serial console, out-of-band An RS-232 connection, using a DB-9 connector, is included on the Management Module for system management.

  • Page 25: Rmon

    SNMP management station. The ELS100-S24TX2M supports four of the nine groups of RMON defined for Ethernet networks on a per segment basis. Specifically, these are: •...

  • Page 26: Auto-Negotiation

    It is not required that the network device being connected to the switch supports auto- negotiation as the ELS100-S24TX2M switch automatically adjusts to the network device’s communication settings. Auto-negotiation is configurable using the console interface menus, the on-board Web agent, or via SNMP.

  • Page 27: Flow Control

    ELS100-S24TX2M switches. Besides balancing the load across each port in the trunk, the additional ports provide redundancy by taking over the load if a port in the trunk should fail. The ELS100-S24TX2M allows up to four RJ-45 ports from a pre-determined selection of ports to be joined together as a trunk.

  • Page 28: Factory Defaults

    100 - 10Mbps ports Port Priority Spanning Tree Protocol Enabled System Configuration BootP Enable Disabled Password <none> Screen Timeout 10 min Send Authentication Fail Traps Enabled SNMP Community Name public, private Terminal Baud Rate Auto User Names admin, guest 12 Product Overview ELS100-S24TX2M...
  • Page 29 Parameter Default Value Virtual LANs Acceptable VLAN Frame Type Configurable PVID Tagging GVRP Disabled Untagged VLAN Group Assignment VLAN Ingress Filtering False VLAN Learning 9033260-01 Product Overview 13...

  • Page 30: Application Examples

    The ELS100-S24TX2M switch is ideal for meeting the needs of today’s high performance networks. The switch’s low cost and high port count makes it attractive and affordable for dedicated 10/100Mbps connections to the desktop.

  • Page 31: Client/Server Network Application

    Client/Server Network Application To improve workstation performance in a client/server environment, the ELS100-S24TX2M switch can be configured to provide 200 Mbps full duplex Fast Ethernet connections to servers by connecting each to a dedicated switch port (Figure 1-4). Users can be accommodated through connections to hubs, both at 10Mbps and 100Mbps speeds, through 10Mbps switches with 100Mbps uplinks, or through direct connections.

  • Page 32: Local Backbone Application

    Local Backbone Application The ELS100-S24TX2M switch can be used in a local backbone application, connecting network segments together and providing file- server access (Figure 1-5). Workgroup hubs are provided with a single connection to the switch while servers are put on dedicated 100 Mbps ports.

  • Page 33: Installation

    2. INSTALLATION Inspecting Your Shipment When you receive the shipment of your switch, check the package contents and make sure you have the following items: • ELS100-S24TX2M stackable switch • Mounting ears and mounting screws • Four rubber feet •...

  • Page 34: Mounting The Switch Or Stack On A Table Or Shelf

    • Environmental Install the ELS100-S24TX2M switch in a dry area, with adequate air circulation. Avoid placing the switch in direct sunlight or near other heat sources, such as hot-air vents. For temperature and humidity specifications, see Appendix A, “Technical Specifications.”...

  • Page 35: Mounting The Switch In A Rack

    Mounting the Switch in a Rack The switch ships with two (2) multi-position mounting ears and four (4) mounting screws. The mounting screws are used to attach the mounting ears to the switch. Once the ears ar e attached to the switch, you will need to provide appropriate screws to mount the switch in a rack.

  • Page 36: Connecting Switches To The Stack's Backplane

    UP port on the last switch. Figure 2-2. Connecting Switches to the Stack’s Backplane Stacking Module and Interconnect Cables Table 2-1 provides information for the Stacking Module and interconnect cables available for the ELS100-S24TX2M. Table 2-1. Stacking Module and Interconnect Cables Par t Number Functions...

  • Page 37: Installing An Optional Module Into The Switch

    Installing an Optional Module into the Switch Optional modules are available for media expansion, stacking and management. These modules can be installed into the modular slots on the rear panel of the switch. The Management Module must be installed in the upper slot, and the Stacking Module in the lower-left slot. The media extension modules can be installed in either of the two lower slots.

  • Page 38: Connecting A Terminal To The Console Port

    Module for connecting to this interface. This cable is shielded to comply with emissions regulations and requirements. Console Port (Out-of-Band) Connections To connect the ELS100-S24TX2M console port to a terminal, do the following: Connect a VT100 compatible terminal or a PC running a terminal emulation program to the console port (Figure 2-4).

  • Page 39: Remote Management Via The Console Port

    Connect the other end of the interface cable to a terminal (in some instances, an adapter may be required to make this connection). From your terminal, start the terminal emulation program. Configure the terminal to the following communication settings: VT100 emulation, 19200 baud, no parity, 8 data bits, 1 stop bit, no flow control, ASCII character set.

  • Page 40: Management Module

    Management Module Table 2-2 provides information for the Management Module available for the ELS100-S24TX2M. Table 2-2. Management Module Part Number Functions Description ELS100-SMGMT RMON/SNMP/ SNMP agent module used to manage the switch (or Web Manage- attached stack). Includes RS-232 serial port for ment console connection.

  • Page 41: Powering The Switch

    Powering the Switch To supply power to the switch, connect the power cord to the switch and to a grounded three-prong wall outlet (Figure 2-5). See Appendix A, “Technical Specifications” on page 29 for more information regarding specific international power cord requirements. Figure 2-5.

  • Page 42: Network Cable Requirements

    Network Cable Requirements Copper Table 2-3 specifies the cable types and length constraints for the various copper interfaces on the ELS100-S24TX2M. Table 2-3. Copper Cable Specifications Interface Type Cable Requirement Maximum Length 10Base-T Category 3 or 5 Unshielded Twisted 100m (328 ft.)

  • Page 43: 10Base-T/100Base-Tx Ports

    Table 2-6 specifies the fiber types, bandwidth requirements, and length constraints for the Gigabit Ethernet long-wavelength fiber interface on the fiber optic media module. Table 2-6. 1000Base-LX Fiber Specifications Fiber Diam eter Modal Bandwidth @ 1300 nm Range (microns) 62.5 µm MMF 500 MHz/km 2-550 Meters 50 µm MMF...

  • Page 44: 100Base-Fx/1000Base-Sx/Lx Fiber Ports

    The 100Base-FX and 1000Base-SX/LX fiber ports use SC connectors. Figure 2-7 shows an SC fiber connector being inserted into a fiber port on the ELS100-S24TX2M. Figure 2-7. Inserting an SC Fiber Connector into a Fiber Port The fiber uplink modules employed (Table 2-7) support multi-mode 62.5/ 125µm fiber and single-mode 10/125µm fiber.

  • Page 45: Appendix A. Technical Specifications

    APPENDIX A. TECHNICAL SPECIFICATIONS General Standards Compliance IEEE 802.1D Transparent Bridging Specifications (ISO/IEC 10038) IEEE 802.1p Traffic Class Expediting and Dynamic Multicast Filtering IEEE 802.1Q Virtual Bridged Local Area Networks IEEE 802.2 Local Area Networks, Logical Link Control (LLC) IEEE 802.3 CSMA/CD 9 (ISO/IEC 8802-3) IEEE 802.3i 10Base-T (ISO/IEC 8802-3, clause 14) IEEE 802.3u 100Base-TX (ISO/IEC 8802-3, clause 25) IEEE 802.3u 100Base-FX...

  • Page 46: Electrical Specifications

    50-60 Hz Maximum power consumption: 80 VA Physical Specifications Height: 2.5 in. (6.4 cm) Length: 11.2 in. (28.5 cm) Width: 17.3 in. (44 cm mountable in a standard 19 in. rack) Weight: 10.63 lb. (4.82 kg) 30 T echnical Specifications ELS100-S24TX2M...

  • Page 47: Port Specifications

    Port Specifications Console Port Table A-1 shows the console port pin assignments. Table A-1. RS-232 Console Port Pin Assignments Signal Name Ground 10Base-T and 100Base-TX Ports Table A-2 shows the 10Base-T/100Base-TX pinouts. These ports are wired MDI-X. All undefined pins are not used. Table A-2.

  • Page 48: Mdi/Mdi-X Crossover Cable Wiring

    Figure A-1. External Crossover Cable Wiring Power Cord Set Requirements The wide-range input feature of the ELS100-S24TX2M Ethernet switch permits it to operate from any line voltage between 100 and 240 VAC. The power cord set (appliance coupler, flexible cord, and wall plug) you received with the switch meets the requirements for use in the country where you purchased the switch.

  • Page 49: Country-Specific Requirements

    Country-Specific Requirements Table A-3 lists the power cord set requirements by country and identifies the accredited agency within that country. Table A-3. Power Cord Set Requirements by Country Country Accredited Agency See Notes * Australia EANSW Austria Belgium CEBC Canada Denmark DEMKO Finland...
  • Page 50 Japanese Dentori Law. Flexible cord must be Type VCT or VCTF, 3-conductor, 0.75mm conductor size. Wall plug must be a two-pole grounding type with a Japanese Industrial Standard C8303 (15A, 125V) configuration. 34 T echnical Specifications ELS100-S24TX2M...

  • Page 51: Appendix B. Flow Control

    Workstation A to stop sending packets by inducing collisions on port X. The pause frame flow control mechanism supported by the ELS100-S24TX2M switch conforms with the IEEE 802.3x specification for full duplex flow control. For the full duplex pause frame mechanism to work, the device connected to the switch port must also support IEEE 802.3x flow control.

  • Page 53: Appendix C. Acronyms & Abbreviations

    APPENDIX C. ACRONYMS & ABBREVIATIONS Term Definition 10Base-T 10 Mbps twisted-pair Ethernet 100Base-TX 100 Mbps twisted-pair Fast Ethernet 100Base-FX 100 Mbps fiber option Fast Ethernet 1000Base-SX 1000 Mbps fiber option short-wavelength Gigabit Ethernet 1000Base-LX 1000 Mbps fiber option long-wavelength Gigabit Ethernet ANSI American National Standards Institute BootP...
  • Page 54 Term Definition SNMP Simple Network Management Protocol TCP/IP Transmission Control Protocol/Internet Protocol TFTP Trivial File Transfer Protocol Transmit Data Unshielded Twisted Pair VLAN Virtual LAN 38 Acronyms & Abbreviations ELS100-S24TX2M...

  • Page 55: Index

    INDEX 1000Base-LX data rates, 29 cables, 27 DB-9 connector, 8 module defined, 6 default settings, 12 1000Base-SX description of switch, 1 cables, 26 dimensions of switch, 30 module defined, 5 downloading software, 8 100Base-FX modules defined, 5 DTE connection, 22 10Base-T/100Base-TX ports, 27 duplex mode, auto-negotiation of, 10 802.1D, 7...
  • Page 56 19 RMON, 9 mounting the switch RS-232 port in a rack, 19 cable connection, 22 on a table or shelf, 18 out-of-band management, 8 multi-mode fiber, 26, 28 pin assignments, 31 rubber foot pads, 18 2 Index ELS100-S24TX2M...
  • Page 57 safety compliance, 29 TCP/IP protocol, 8 SC ports, 28 Telnet, 8, 23 screws, mounting, 19 terminal connection, 8, 22 SCSI II ports, 6 tests, hardware and software, 25 serial port TFTP download, 8 connecting to, 22 traffic priority, 11 out-of-band management, 8 transmit queues, 35 pin assignments, 31 trunking, 11...
