• Temperature: Multi-pair PVC 24 AWG telephone cables typically
have an attenuation of approximately 8-10 dB/100 m at 20 C (68 F).
The attenuation of PVC insulated cable varies significantly with
temperature. At temperatures greater than 40 C (104 F), we strongly
recommend using plenum-rated cable to ensure attenuation remains
within specification.
D.1.2

Multimode Fiber Optic Network

When connecting a multimode fiber optic link segment to the
ESXMIM-F2 or a hub (using an EPIM-F1/F2), ensure the network meets
the following requirements:
• Cable Type: Use the following multimode fiber optic media:
- 50/125 m fiber optic cabling
- 62.5/125 m fiber optic cabling
- 100/140 m fiber optic cabling
• Attenuation: You must test the fiber optic cable with a fiber optic
attenuation test set adjusted for an 850 nm wavelength. This test
verifies that the signal loss in a cable falls within the following
acceptable levels:
- 13.0 dB or less for a 50/125 m fiber cable segment
- 16.0 dB or less for a 62.5/125 m fiber cable segment
- 19.0 dB or less for a 100/140 m fiber cable segment
• Budget and Propagation Delay: When you determine the maximum
fiber optic cable length to incorporate fiber runs into your network, you
must calculate and consider the fiber optic budget (a total loss of
10.0 dB or less is permissible between stations) and total network
propagation delay.
To determine the fiber optic budget, combine the optical loss due to
the fiber optic cable, in-line splices, and fiber optic connectors.
Typical loss for a splice and connector (together) equals 1 dB or less.
ESXMIM/ESXMIM-F2 Installation Guide
Network Requirements
D-3
