CONTROLS AND INDICATORS
This chapter identifies and describes the components and operational
indicators of the ESXMIM.
2.1
PARTS OF THE ESXMIM
In some instances, the ESXMIM and ESXMIM-F2 provide different front
panel connectivity options, LED indicators, or other labeling. In these
instances, the configuration of the ESXMIM will be discussed first.
2.1.1
The Faceplate
BRIM Slot
EPIM Slot
ESXMIM/ESXMIM-F2 Installation Guide
CHAPTER 2
01
Figure 2-1 The ESXMIM Faceplate
Reset Switch
LANVIEW LEDs
Knurled Knobs
RJ45 Ports
Serial Ports
2-1
