4.2

TROUBLESHOOTING CHECKLIST

If your ESXMIM is not operating properly, the following checklist
describes some of the problems that may occur with the ESXMIM
installed in an MMAC, possible causes for the problem, and suggestions
for resolving the problem.
Condition
All LEDs are off.
No Local
Management
Password Screen.
ESXMIM/ESXMIM-F2 Installation Guide
Possible Cause
Loss of power
to the MMAC
ESXMIM not
properly
installed
MMAC power
bus failure
ESXMIM
connector pin
damage
Incorrect
terminal setup
Improper
console cable
pinout
Troubleshooting Checklist
Recommended Action
Check the proper installation of the
MMAC power supply module and
its access to a live outlet. Check
power cables for viability.
Check that the MMAC has
adequate power. Some
configurations, especially those
including FDDI modules, require
that more than one power supply
be installed in the MMAC.
Check to see that all power supply
LEDs are green.
Re-install ESXMIM in hub
according to instructions in
Chapter 3.
Install ESXMIM in a different
MMAC slot.
Examine ESXMIM backplane
connectors for evidence of bent or
broken pins.
Review terminal or emulation
settings for accordance with
requirements.
Refer to Appendix A for proper
console port pinouts.
4-3
