Appendix A: Specifications
A.3

ENVIRONMENTAL REQUIREMENTS

Operating Temperature
Storage Temperature
Operating Humidity
Waste Heat Production under normal conditions:
ESXMIM
ESXMIM-F2
A.4

CERTIFICATION

Safety
Emission
Immunity
A.5

COM PORT PINOUT

Type: Standard RJ45 port
Pin Function
1 Transmit Data (XMT)
2 Data Carrier Detect (DCD)
3 Data Set Ready (DSR)
4 Receive Data (RCV)
5 Signal Ground (GND)
6 Data Terminal Ready (DTR)
7 Request to Send (RTS)
8 Clear to Send (CTS)
A-2
5 C to 40 C (41 F to 104 F)
-30 C to 90 C (-22 F to 194 F)
5% to 95% (non-condensing)
approx. 245 BTU/hr
approx. 270 BTU/hr
UL 1950, CSA C22.2 No. 950, EN 60950, and
IEC 950
FCC Part 15 Class A, VCCI Class i, and
EN 55022 Class A
EN 50082-1
Connection Attitude
From COM 2 port
From COM 2 port
To COM 2 port
To COM 2 port
NA
From COM 2 port
To COM 2 port
NA
ESXMIM/ESXMIM-F2 Installation Guide
