3.5
CONNECTING TO THE NETWORK
This section gives procedures for connecting the ESXMIM and various
EPIMs to the network. Refer to the list below and follow the procedures
in the subsection for appropriate module type:
•
Connecting a 10BASE-T Segment to the ESXMIM: Section 3.5.1
•
Connecting a 10BASE-F Segment to the ESXMIM-F2:
Section 3.5.2
•
Connecting a 10BASE-T Segment to an EPIM-T: Section 3.5.3
•
Connecting a 10BASE-F Segment to an EPIM-F2 or EPIM-F3:
Section 3.5.4
•
Connecting a 10BASE-F Segment to an EPIM-F1: Section 3.5.5
•
Connecting an AUI Segment to an EPIM-X or EPIM-A:
Section 3.5.6
•
Connecting a 10BASE2 Segment to an EPIM-C: Section 3.5.7
ESXMIM/ESXMIM-F2 Installation Guide
Connecting to the Network
3-11
