Chapter 4: Troubleshooting
Table 4-1 LANVIEW LED Messages (Continued)
LED Color
Green
RCV
Amber
Green
XMT
Amber
4-2
Description
Valid link
Receiving traffic
Transmitting packet
Port in standby
ESXMIM/ESXMIM-F2 Installation Guide
Error Condition/
Recommended Action
If a segment RCV LED does
not light, check the segment
cable and the status of any
connecting devices. Ensure
that all connected ports are
enabled. Ensure that the
network is actually producing
Ethernet traffic.
If none of the transmit LEDs
are flashing, the ESXMIM is
not transmitting frames on
any of the segments. Ensure
that the network is actually
producing Ethernet traffic.
Contact Cabletron Systems
Technical Support for
assistance
Flashing Amber indicates the
port has been placed in
standby mode by the
operation of the Spanning
Tree Algorithm.
