Chapter 2: Controls and Indicators
BRIM Slot
EPIM Slot
Knurled Knobs
The black plastic knurled knobs on the faceplate of the ESXMIM are used
to turn the securing screws that hold the ESXMIM module in place in the
MMAC chassis.
BRIM Slot
The BRIM slot is a covered opening in the faceplate that can be
configured with a BRIM module. For a list of BRIM modules available
for use in the ESXMIM, refer to Appendix B, BRIM/EPIM
Information.
2-2
Figure 2-2 The ESXMIM-F2 Faceplate
ESXMIM/ESXMIM-F2 Installation Guide
Reset Switch
LANVIEW LEDs
Knurled Knobs
ST Ports
Serial Ports
02
