Appendix C: Upgrading the ESXMIM
C.2

ADDING EPIMS

This section contains procedures for adding or replacing an Ethernet Port
Interface Module (EPIM) to upgrade or change the capabilities of your
ESXMIM. After installing your new EPIM, refer to Chapter 3,
Installation, for network connection instructions.
Observe all antistatic precautions when handling sensitive
!
electronic equipment.
CAUT ION
To install an EPIM, perform the following steps:
When removing an existing EPIM, make sure to pull the
!
module straight out to avoid damage to the connector.
CAUT ION
1. Remove the coverplate or the existing EPIM (whichever applies).
2. Slide your new EPIM into place, making sure the connectors on the
rear of the module and inside the ESXMIM attach properly. Refer to
Figure C-2.
3. Install the mounting screw.
C-2
ESXMIM/ESXMIM-F2 Installation Guide
