This appendix lists the BRIM modules and EPIM modules which may be
used within the Cabletron Systems ESXMIM.
B.1

ESXMIM-CAPABLE BRIMS

The ESXMIM supports the incorporation of the following BRIMs:
BRIM-A100: ATM BRIM. The BRIM-A100 supports a 100 Mbps ATM
connection through the use of a single Fixed Shroud Duplex (FSD) port.
BRIM-A6: ATM BRIM. The BRIM-A6 supports the use of ATM Port
Interface Modules (APIMs). The following APIM types will operate in an
ESXMIM-based BRIM-A6:
• APIM-11: 100 Mbps TAXI interface with one multimode fiber optic
SC port
• APIM-21: 155 Mbps OC-3 interface with one multimode fiber optic
SC port
• APIM-29: 155 Mbps OC-3 interface with one single mode fiber optic
SC port
• APIM-22: 155 Mbps STS3 interface with one Category 5 UTP RJ45
port
• APIM-67: 45 Mbps DS3 interface with 75 BNC connectors
BRIM-A6 DP: ATM BRIM. The BRIM-A6 DP supports the use of the
same APIMs as the BRIM-A6 (above).
BRIM-E6: 10 Mbps Ethernet BRIM. The BRIM-E6 supports the use of
EPIMs. The EPIM types that are currently available are listed in Section
B.2, ESXMIM-Capable EPIMs.
BRIM-E100: 100 Mbps Fast Ethernet BRIM. The BRIM-E100 supports
the use of Fast Ethernet Interface Modules. The following Fast Ethernet
Interface Modules will operate in an ESXMIM-based BRIM-E100:
• FE-100TX: Category 5 UTP interface with one RJ45 port
• FE-100FX: Multimode fiber optic interface with one duplex SC port
