6. Switch Configuration

This chapter explains how to set up the SmartStack STS16-20D/STS16-20R and to
modify the configuration using a VT100 console attached to the switch directly or
via a modem connection. The switch configuration can also be modified from a
remote VT100 console via a telnet session.
For information on how to connect the console, see Chapter 5, "Accessing Switch
Management".
Subjects covered in this chapter:
•
General guidelines (page 76)
•
Main menu screen (page 78)
•
Configuration menu (page 79)
•
Switch and stack configuration (page 80)
•
Module information (page 84)
•
Virtual LANs (page 86)
•
IP configuration (page 94)
•
Spanning tree protocol (STP) (page 97)
•
Port configuration (page 106)
•
CrossLink channels (page 110)
•
Address filtering (page 116)
•
Address aging (page 126)
•
Console password (page 130)
•
Console/Telnet sessions (page 132)
•
Syslog facility (page 139)
•
DSRR configuration page 141()
•
Download/Upload menu (page 147)
•
Reset menu (page 152)
