General Guidelines

To work within the console menus and screens, follow these guidelines:
•
To select an item on a screen or a menu, highlight it by using the arrow keys
and then press
item—for example, selecting Yes or No or supplying a value—a prompt
appears on the screen.
•
In most cases, new values are saved when you select Return.
•
The More item means there is more information than what is displayed on that
screen. Selecting More and pressing
information.
•
Port refers to the number of a specific port on an switch.
•
Index refers to the numerical order of a list.
•
To return to the main menu from any screen, press
changes made to the screen you were in will not be saved when you do this. To
return to the greeting screen, press
•
To refresh the console screen, press
•
If you are administering switches in a stack, many of the console screens will
prompt for a box number. Enter the number of the box you want to administer.
•
The "VLAN" term in connection with CRF is discussed on page 31.
•
The terms "Virtual LAN" and "domain" are interchangeable.
•
The console automatically returns to the greeting screen after five minutes of
inactivity. Five minutes is the default value. The time can be changed at the
Console Configuration menu as explained later in this chapter.
To open the Console Configuration menu from the main menu, select
Configuration
•
For protection against inadvertent or unauthorized access to configuration
screens, you may establish a password that users must enter at the greeting
screen. In release 4.0 (and later) two types of users can be defined:
Read-only users:
These users cannot modify any of the configuration parameters.
They can read everything (except the SNMP communities).
Read-write users:
These users have full access to all configuration parameters.
SmartStack STS16-20D/STS16-20R Token Ring Switches Installation and User Guide
. If you need to specify additional information for that
ENTER
Console Configuration.
displays the next screen of
ENTER
CTRL-P
.
CTRL-B
.
CTRL-L
. Note that any
Switch Configuration
