Management

This section describes the management options for the switch.

SNMP

The SmartStack STS16-20D/STS16-20R can be managed via a SNMP manager.
The SmartStack STS16-20D/STS16-20R supports ten Management Information
Bases (MIBs). Six of the MIBs are standard MIBs, which are defined by RFCs and
are included with most SNMP management applications. Four of the MIBs are
proprietary and are provided on the disk that accompanies the SmartStack STS16-
20D/STS16-20R. SNMP management is supported via IP and MAC.
The following MIBs are supported:
Specification
RFC1213
RFC1493
RFC1525
RFC1573
RFC1757/1513
RFC1749/1748
DTR MIB
DTR MAC MIB
STS16 MIB
STS16 MIB

Table 8. Supported MIBs

Most user configurable variables will be supported in either the standard MIBs or
the proprietary MIB. Configuration settings, such as port attributes, and operational
information, such as address tables, are fully accessible through SNMP. Certain
other settings, such as passwords and console settings, cannot be viewed or
modified via SNMP for security reasons.
Switch Overview
MIB II
Bridge MIB
SR Bridge MIB
Evolution of the Interfaces Group of MIB-II
RMON MIB/TR extensions - Only partial support
IEEE 802.5 MIB
IEEE 802.5r MIB
IEEE 802.5r MIB
1.3.6.1.4.1.52.285
1.3.6.1.4.1.9 (crosslinks)
SmartStack STS16-20D/STS16-20R Token Ring Switches Installation and User Guide
MIB
35
