Back Panel Details
The back panel of the switches are illustrated in
Figure 3. The back panel of the SmartStack STS16-20D
Figure 4. The back panel of the SmartStack STS16-20R
Table 4 lists the back panel connectors on the switch.
Name
AC connection
Redundant power
supply
(SmartStack
STS16-20R only)
Table 4. Back Panel Connectors
Introduction
Standard AC power connection.
Connector for the optional redundant power supply unit.
SmartStack STS16-20D/STS16-20R Token Ring Switches Installation and User Guide
Description
9
