14
Performance
Specification
Maximum frame rate per port
Maximum aggregate frame
rate per 4 ports
Throughput per port
Aggregate switching rate
(unicast or broadcast) for
entire switch
Within switch latency (cut-
through)

Table 6. Performance Specifications

SmartStack STS16-20D/STS16-20R Token Ring Switches Installation and User Guide
Value
57,000 pps in each direction (measured with
a frame size of 19 bytes)
200,000 pps in each direction. Full media
speed for frame sizes above 28 bytes
16 Mbps in each direction for all frame sizes
1,500,000 pps for smallest frame sizes
35 µs
Introduction
