206
Add Entry
Adds a new entry to the trap receiver table.
Delete Entry
Deletes an entry from the trap receiver table.
Change Entry
Modifies an entry in the trap receiver table.
Clear Table
Deletes all table entries.
Zoom
Displays the complete list of BRFs assigned to an IP address.

List of Supported Traps from a STS16-20D/STS16-20R

General traps
The coldStart Trap
A coldStart trap signifies that the sending protocol entity is (re)initializing itself.
Sending this trap indicates that the agent's configuration or the protocol entity
implementation may have been altered.
The warmStart Trap
A warmStart trap signifies that the sending protocol entity is reinitializing itself
such that neither the agent configuration nor the protocol entity implementation is
altered.
The linkDown Trap
A linkDown trap signifies that the sending protocol entity recognizes a failure in
one of the communication links represented in the agent's configuration.
The Trap-PDU of type linkDown contains as the first element of its variable-
bindings, the name and value of the ifIndex instance for the affected interface.
The linkUp Trap
A linkUp trap signifies that the sending protocol entity recognizes that one of the
communication links represented in the agent's configuration has come up.
The Trap-PDU of type linkUp contains as the first element of its variable-bindings,
the name and value of the ifIndex instance for the affected interface.
The authenticationFailure Trap
SmartStack STS16-20D/STS16-20R Token Ring Switches Installation and User Guide Monitoring the Network with SNMP
