4. At power on (cold boot), the SmartStack STS16-20D/STS16-20R performs a
series of self-test diagnostics verifying that hardware components are
functioning. An example of the self-test diagnostic screen is shown later in this
chapter.

Communication Problems

If the diagnostic list does not appear, or is garbled, try adjusting the baud rates
between the console and the SmartStack STS16-20D/STS16-20R by using the
Autobaud routine within the switch. To do this, press the reset button on the front
of the switch and wait for the internal diagnostics to finish (the DIAG LED turns
off). The reason for the reset is that in case the switch's Autobaud routine is
disabled, resetting it will set it to its default mode Autobaud enabled.
Depending on the type of the console, there are several console command keys that
will potentially initiate the Autobaud routine in the SmartStack STS16-20D/
STS16-20R. Four of these keys are
key, and
BREAK
After the DIAG LED turns off, try one of the command keys at the console, and
press it repeatedly. If there is no response, wait several seconds and again, press it
repeatedly. If necessary, perform the same routine using the other command keys.
If this does not work, and there is garbled output on the screen, try pushing the
unlabeled system request button on the SmartStack STS16-20D/STS16-20R. As
soon as garbled characters appear, press the console's
twice in rapid succession. (Again, try the other command keys as necessary).
If the problem remains, try the following steps:
1. Check all of the cable connections.
2. Check the baud rate at the console's set up screen; if it is not set to 9600, try this
setting.
3. Try setting the console baud rate to different values up or down, and pressing
RETURN
4. If you are using a terminal emulation program, try exiting the program and
restarting.
SmartStack STS16-20D/STS16-20R Token Ring Switches Installation and User Guide
Disable the "Use Function, Arrow, and Ctrl
Keys for Windows" option located in the
Terminal Preference menu
.
ESC
for each selection.
Value
, the combination keys
RETURN
ENTER (
, the
ALT-B
or key
RETURN)
Accessing Switch Management
