89
View...
Zooms in a VLAN.
Add...
Prompts for a new ID and brings up the VLAN Parameter Configuration screen.
Change...
Prompts for a numeric ID of a BRF or CRF to change and brings up the VLAN
Parameter Configuration screen.
Delete
Lets you delete a BRF or CRF. You cannot delete a BRF if there are CRFs assigned
to it, or a CRF if there are ports assigned to it.
VLAN Parameter Configuration for CRF Screen
To open this screen, do the following:
1. From the main menu, select Configuration
VLAN Configuration
VLAN Configuration.
2. Select View..., Add..., or Change...
3. When prompted, enter the VLAN ID for the CRF.
Use this screen to add or change a CRF. Note that the trcrf-default cannot be
deleted. Also, the trcrf-default cannot be assigned to other BRFs.
The following information is displayed on this screen:
Switch Configuration
SmartStack STS16-20D/STS16-20R Token Ring Switches Installation and User Guide
