You can configure QoS policies for the following types of traffic:
• Layer-2 prioritization (802.1p)
• Layer-3 source-destination flows
• Layer-4 source-destination flows
• Layer-4 application flows
Statistics
The SSR can provide extensive statistical data on demand. You can access the following
types of statistics:
• Layer-2 RMON and MIB II Statistics – Port statistics for normal packets and for errors
(packets in, packets out, CRC errors, and so on)
• Layer-3 RMON v2 Statistics – Statistics for ICMP, IP, IP-interface, IP routing, IP
multicast, VLAN
• Layer-4 RMON v2 Statistics – Statistics for TCP and UDP

Management Platforms

You can manage the SSR using the following management platforms:
• Command Line Interface (CLI) – An Emacs editor-like interface that accepts typed
commands and responds when applicable with messages or tables. You will use the
CLI to perform the basic setup procedures described in
• CoreWatch – Cabletron Systems's Java-based device management software.
CoreWatch provides a graphical interface to the SSR, providing most of the same
monitoring and control features as the CLI.
• SNMP MIBs and traps – The SSR supports SNMP v1 and many standard networking
MIBs. You access the SSR's SNMP agent using integration software for HP OpenView
5.x on Windows NT or Solaris 2.x, or Cabletron SPECTRUM on Solaris 2.x.
in this guide explains how to set up SNMP on the SSR.
access the SSR's SNMP agents.
SSR 8000/8600 Getting Started Guide
Chapter 1: Features Overview
Chapter 3 of this guide.
Chapter 3
Chapter 4 explains how to
