Cabletron Systems SmartSwitch Router User's Reference Manual page 326

Chapter 22: WAN Configuration Guide
• Committed information rate (CIR) of 20 million bits per second
• Leave high-, low-, and medium-priority queue depths set to factory defaults
• Random Early Discard (RED) disabled
• RMON enabled
The command line necessary to set up a service profile with the above attributes would be
as follows:
ssr(config)# frame-relay define service profile1 Bc 2000000 Be 10000000
becn-adaptive-shaping 65 cir 20000000 red off rmon on
To assign the above service profile to the VC interface created earlier (slot 4, port 1):
ssr(config)# frame-relay apply service profile1 ports hs.4.1.100
326 SmartSwitch Router User Reference Manual
