RMON Groups

The RMON MIB groups are defined in RFCs 1757 (RMON 1) and 2021 (RMON 2). On the
SSR, you can configure one or more levels of RMON support for a set of ports. Each
level—Lite, Standard, or Professional—enables different sets of RMON groups (described
later in this section). You need to configure at least one level before you can enable RMON
on the SSR.
To specify the support level for RMON groups, use the following CLI command line in
Configure mode:
Specifies Lite, Standard, or
Professional RMON groups.
To specify the ports on which RMON is to be enabled, use the following CLI command
line in Configure mode:
Specifies the ports on which
RMON is enabled.
You can configure each level of RMON support independently of each other with default
tables on or off. For example, you can configure Lite with default tables on for ports
et.1.(1-8) and then configure Standard with no default tables for the same ports. You
cannot configure Lite on one set of ports and Standard on another set of ports.

Lite RMON Groups

This section describes the RMON groups that are enabled when you specify the Lite
support level. The Lite RMON groups are shown in the table below.
Table 6. Lite RMON Groups
EtherStats
Event
Alarm
History
SmartSwitch Router User Reference Manual
Group
Records Ethernet statistics (for example, packets dropped,
packets sent, etc.) for specified ports.
Controls event generation and the resulting action (writing a
log entry or sending an SNMP trap to the network
management station).
Generates an event when specified alarm conditions are met.
Records statistical samples for specified ports.
Chapter 21: RMON Configuration Guide
rmon set lite|standard|professional default-
tables yes|no
<port list>
rmon set ports
Function
|allports
