To display the RMON 2
Address Map table.
To show Network Layer Host
logs.
To show Application Layer
Host logs.
To show Network Layer
Matrix logs.
To show Application Layer
Matrix logs.
To show all Network Layer
Matrix Top N.
To show all Application
Layer Matrix Top N.
To show all user history logs.
To show probe configuration.
1
To display Ethernet statistics and related statistics for WAN ports, RMON has to be
activated on that port. To activate RMON on a port, use the frame-relay define service or
ppp define service command, and the frame-relay apply service or ppp apply service
command. For addional information, refer to
on page 324

RMON CLI Filters

Because a large number of statistics can be collected for certain RMON groups, you can
define and use CLI filters to limit the amount of information displayed with the rmon
show commands. An RMON CLI filter can only be applied to a current Telnet or Console
session.
SmartSwitch Router User Reference Manual
rmon show address-map <port-list>|all-ports
rmon show nl-host<port-list>|all-ports [summary]
rmon show al-host<port-list>|all-ports [summary]
rmon show nl-matrix<port-list>|all-ports [order-by
srcdst|dstsrc] [summary]
rmon show al-matrix<port-list>|all-ports [order-by
srcdst|dstsrc] [summary]
rmon show nl-matrix-top-n
rmon show al-matrix-top-n
rmon show user-history
rmon show probe-config [basic] [net-config] [trap-
dest]
(for frame relay) and "Setting up a PPP Service Profile" on page 328
Chapter 21: RMON Configuration Guide
"Setting up a Frame Relay Service Profile"
(for PPP).
