Configuring the SSR for Port Mirroring

The SSR allows you to monitor activity with port mirroring. Port mirroring allows you to
monitor the performance and activities of one or more ports on the SSR or for traffic
defined by an ACL through just a single, separate port. While in Configure mode, you can
configure your SSR for port mirroring with a simple command line like the following:
Configure Port
Mirroring.
Note: • Port mirroring is available for WAN ports. However, you cannot configure port
• Only IP ACLs can be specified for port mirroring.

Monitoring Broadcast Traffic

The SSR allows you to monitor broadcast traffic for one or more ports. You can specify
that a port be shut down if its broadcast traffic reaches a certain rate limit for a particular
period of time. You can also specify the duration of the port shut down. To specify the
monitoring of broadcast traffic and the shut down threshold for one or more ports, enter
the following command in Configure mode:
Configure monitoring of
broadcast traffic.
SmartSwitch Router User Reference Manual
port mirroring monitor-port
mirroring on a port-by-port basis. (You can only configure port mirroring for
the entire WAN card).
port bmon
Chapter 20: Performance Monitoring Guide
<port list>
port |target-profile
<port list>
rate
<number> <number>
shutdown
<port number>
target-
<acl name>
<number>
duration
