1.6

Jumper Settings

Properly configure jumper settings on the PSB501 to meet your application purpose. Below you
can find a summary table of all jumpers and onboard default settings.
Note: How to setup Jumpers
Illustrations below show that a cap on a jumper is to "close" the jumper, whereas that off a jumper
is to "open" the jumper.
[Open]
Jumper
JP2 Clear RTC : Normal
JP5&J61 DELAY Function SW
1.6.1

Restore BIOS Optimal Defaults (JP3)

Put jumper clip to pin 2-3 for a few seconds and then move it back to pin 1-2. Doing this
procedure can restore BIOS optimal defaults.
Function
Normal operation (default)
Restore BIOS optimal defaults
1.6.2 DELAY Function SW (JP5&JP6)
JP6
2-3 close
2-3 close
1-2 close
Introduction
[Closed]
Descriptions
Setting
1-2 close
2-3 close
JP5
2-3 close Delay power on 3s
1-2 close Delay power on 6s
Disable delay function
1-2 close
(default)
[Pin1-2 Closed]
1-2 close
1-2 close
function
IPC970 Series User's Manual
Setting
15
