1 x Remote switch & reset switch
4
1 x VGA & 1 x HDMI & 1 x AT/ATX selectable switch (default ATX)
5
6 x USB3.2 Gen.2
6
2 x USB3.2 Gen.1
7
8 1 x i211-AT, 1 x i225-LM
9 1 x Ground terminal
10 1 x 4-pin terminal block
11 Extension system I/O module
(1) AX93511: 4 x RS-232/422/485 module
(default RS-232) (optional)
(2) AX93512: 2 x RS-232/422/485 with
isolated 1.5kVDC & 8-in/8-out with
isolated 1.5kVDC DIO module (optional)
(3) AX93516: 4 x RS-232/422/485 with
isolated 2kVDC module (optional)
(4) AX93519: 1 x 10/100/1000 Mbps (Intel®
i211-AT) Ethernet, 2 x RS-232/422/485,
and 2 x USB 3.0(USB2.0 signal) module (optional)
(5) Blank I/O cover (default)
2 x 2.5" SSD/HDD drive bay
12
13 3 x Expansion slot
1 x USB2.0 type A connector
14
