1.7.14 AT/ATX Power On/OFF Button (SW1)

The AT/ATX power button is on the I/O side. It allows users to control SBC87519 power
on/off.
Function Description
On Turn on/off system
Off Keep system status

1.7.15 AT/ATX Switch (SSW1)

If you set AT/ATX switch to AT mode, the system will be automatically powered on without
pressing the soft power button during power input. We can use this switch to achieve auto power
on demand.
Introduction
IPC970 Series User's Manual
25
