IPC970 Series User's Manual
Step 5 Remove the antenna plug from the front side, and then install the antenna on
the antenna connector. The installation is complete.
Note:Please use the supplied extended bracket when using a half-size Mini
card.
2.3
Installing the 5G Module
The IPC970 comes with a M.2 Key B 3040/3050 socket for users to install a 5G wireless module.
Please refer to the following instructions and illustrations for the installation of the 5G module.
Step 1
Turn off the system.
Step 2
Disconnect the power connector.
Step 3
Loosen 4 screws to remove the expansion cover(2) from the chassis.
38
Hardware Installation
