Name
GPS source address P3292 U8
GPS2 source address P3293 U8
VSP source address P3294 U8
MMI source address P3295 U8
SASA sensor source
P3296 U8
address
PVED-CLS source
P3297 U8
address
Wheel Angle Sensor
P3298 U8
source address
AUX device (mini-
steering wheel) source P3299 U8
address
AUX device (joystick)
P3300 U8
source address
Name
PGN offset to Vehicle
P3318 U8
speed message
PGN offset to SASA
P3319 U8
messages
PGN offset to Wheel
P3320 U8
Angle Sensor messages
PGN offset to AUX mini-
steering wheel P3321 U8
messages
PGN offset to AUX
P3322 U8
joystick messages
PGN offset to Steering
P3323 U8
Feedback Message
PGN type for MMI P3324 U8
PGN offset for MMI P3325 U8
Description of parameter
dec J1939 Source Address of the Auto-guidance controller
dec J1939 Source Address of a second Auto-guidance controller
dec J1939 Source Address of the vehicle speed sensor
dec J1939 Source Address of the MMI
dec J1939 Source Address of the SASAIID sensor
dec J1939 Source Address of the PVED (avoid using 127 and 241)
dec J1939 Source Address of the WAS
dec J1939 Source Address of the AUX device (mini-steering wheel)
dec J1939 Source Address of the AUX device (joystick)
Description of parameter
dec PGN offset to Vehicle speed message
dec PGN offset to SASA messages
dec PGN offset to Wheel Angle Sensor messages
dec PGN offset to AUX device (mini steering wheel) messages
dec PGN offset to AUX device (joystick) messages
dec PGN offset to Steering Feedback Message
PGN type for MMI message:
dec
Proprietary A = 0; Proprietary B = 255
dec PGN offset for MMI message
OEM
OEM
OEM
OEM
OEM
OEM
OEM
OEM
OEM
Table 6
OEM
OEM
OEM
OEM
OEM
OEM
OEM
OEM
Table 7
Range
0 253 28
0 253 29
0 253 251
0 253 252
0 253 77
0 253 19
0 253 250
0 253 79
0 253 78
Range
0 255 64,65*
0 255 16,17*
0 255 18,19*
0 255 20,21*
0 255 22,23*
0 255 24
0 255 0
0 255 66, 67*
