13 Control panel

13.1 Control panel on instrument console

1. Sign out button
2. Patient recognition (display only)
3. Time (display only)
4. Motorised headrest mode (optional, display
only)
5. Date (if configured, display only)
6. Maintenance button
7. Assistant call / Door open
8. Chair buttons
9. Wireless foot control battery (optional, display
only)
10. User name (display only)
11. Romexis connection (optional, display only)
User's manual
12. Bluetooth connection enabled (optional,
display only)
13. Unit buttons
14. Customisable swipe menu. Swipe to the side
to view more functions
15. Timer button
16. Wireless foot control button (optional)
17. Apex locator button (optional)
18. Touchpad button (optional)
19. X-ray film viewer button
20. Solanna Vision button (optional)
21. Program button
