Properties; Get Info From Relay; Send Info To Relay - GE Multilin MIB Instruction Manual

4.2 FILE 4 COMMUNICATIONS

4.2.3 PROPERTIES

From the File – Properties option, the program will show a screen including the relay model information, firmware
version, etc., as shown on Figure 4–3:
4
Figure 4–3:

4.2.4 GET INFO FROM RELAY

The File – Get info from relay option enables the user to save the relay settings in a file on the hard disk of the
computer. This file can later be opened offline to review and modify settings, and send them again to the relay after the
modifications.

4.2.5 SEND INFO TO RELAY

The File – Set info to relay option enables to send to the relay a settings file stored on the hard disk of the computer.
4-4 MIB High Impedance Bus Differntial Relay GEK-106426B
